Hello! I'm @Ryo54388667! ☺️

I work as an engineer in Tokyo, primarily dealing with TypeScript and Next.js technologies.

Today, I'll thoroughly explain the image optimization errors that occur when combining CloudFront and Next.js, sharing my journey from encountering the problem to achieving a complete solution!

This article is especially helpful for those struggling with the "url parameter is not allowed" error when accessing staging environments via CloudFront, or those experiencing image display issues with App Runner and CloudFront integration.

Problem Overview 📋

Symptoms Encountered

Let me start by detailing the problem I encountered.

Environment Setup

Backend: AWS App Runner
CDN: CloudFront
Framework: Next.js (with image optimization features)

Browser

image 404...😭

Error Details

/_next/image?url=%2Ficons%2Fgithub.webp&w=48&q=75
↓
400 Bad Request: "url" parameter is not allowed

Have you seen this error before? 😅 When accessing through a CloudFront domain (xxxxxx.cloudfront.net), the site itself displays correctly, but only the images appear as blank white spaces.

Why Does This Problem Occur?

Through investigation, I discovered three root causes for this issue:

Host Header Mismatch Issue
- CloudFront sends requests to App Runner with the Host header still set to the CloudFront domain
- App Runner expects requests with its own domain name, causing routing failures
- Example: CloudFront sends Host: xxxxxx.cloudfront.net but App Runner expects Host: xxxxx.ap-northeast-1.awsapprunner.com
Query Parameter Forwarding Issues
- Query parameters required for Next.js image optimization (url, w, q) are not properly forwarded
- CloudFront configuration may discard query parameters
- Example: Parameters in /_next/image?url=%2Ficons%2Fgithub.webp&w=48&q=75 don't reach the destination
Base URL Configuration Conflicts
- Mismatch between NEXT_PUBLIC_BASE_URL settings and access domain
- This configuration error can trigger circular dependency errors
- Next.js references incorrect base URLs when internally generating image optimization URLs

How Next.js Image Optimization Works

Let me briefly explain Next.js image optimization functionality:

// Next.js Image component usage example
import Image from 'next/image'

export default function MyComponent() {
  return (
    <Image
      src="/icons/github.webp"
      alt="GitHub Icon"
      width={48}
      height={48}
    />
  )
}

This component actually generates URLs like this:

/_next/image?url=%2Ficons%2Fgithub.webp&w=48&q=75

url: Original image path (URL encoded)
w: Display width
q: Quality (1-100 value)

This /_next/image endpoint is Next.js's image optimization API, which resizes and optimizes images in real-time. Therefore, if query parameters don't reach this endpoint correctly, images won't display.

Initially, I wondered "Why do only images fail...?" but it's because only the image optimization feature requires special query parameters, while other resources displayed normally.

Trial and Error Process Toward Solution 🔍

Phase 1: Initial Diagnosis and Basic Fixes

I first tried reviewing basic configurations.

# Terraform configuration check
terraform plan
terraform apply

# App Runner and CloudFront status verification
aws apprunner describe-service --service-arn xxx
aws cloudfront get-distribution --id xxx

At this stage, I changed NEXT_PUBLIC_BASE_URL to the CloudFront domain, which was a major mistake 😅

// ❌ Incorrect configuration
NEXT_PUBLIC_BASE_URL=https://xxxxxx.cloudfront.net

// This configuration caused circular dependency errors

Circular dependency errors occurred, making the App Runner service itself unstable.

Circular Dependency Error Details:

Next.js app references the CloudFront domain specified in NEXT_PUBLIC_BASE_URL
CloudFront forwards that request back to App Runner
App Runner redirects again to the CloudFront domain
This repetition creates an infinite loop

At this point, I realized that "basic configuration changes alone won't solve this."

Phase 2: Detailed CloudFront Configuration Adjustments

Next, I tried making more granular adjustments to CloudFront settings.

# Configuration example attempted
ordered_cache_behavior {
  path_pattern     = "_next/image*"
  allowed_methods  = ["GET", "HEAD", "OPTIONS"]
  cached_methods   = ["GET", "HEAD", "OPTIONS"]

  cache_policy_id            = "4135ea2d-6df8-44a3-9df3-4b5a84be39ad" # CachingDisabled
  origin_request_policy_id   = "216adef6-5c7f-47e4-b989-5492eafa07d3" # AllViewer
}

This configuration showed temporary improvement, but the AllViewer policy caused compatibility issues with App Runner. Particularly, unexpected behavior occurred with Host Header handling, affecting other endpoints as well.

Specific problems with AllViewer policy:

Host Header forwarded as CloudFront domain
App Runner routing triggers CORS errors
Impact spreads to other API endpoints (/api/*)
Response times become abnormally long (timeouts occur)

Thinking "Managed policies sometimes have traps..." I decided to try the next approach.

Phase 3: Reverting to Legacy Settings

Due to managed policy issues, I tried reverting to legacy forwarded_values settings.

# Configuration example attempted
forwarded_values {
  query_string = true  # Forward all query parameters
  headers      = ["Origin", "Accept", "Host"]

  cookies {
    forward = "none"
  }
}

This configuration made the site display, but the 400 error for images persisted.

At this point, I was convinced that "the cause lies in something more fundamental than configuration issues" and began deeper investigation.

Final Solution Discovery and Implementation 💡

Root Cause Identification

Through web research, the following crucial facts emerged:

CloudFront's CORS-S3Origin policy doesn't forward query parameters
- Designed for S3, it doesn't support dynamic query parameter forwarding
- Inappropriate for dynamic processing like Next.js image optimization
App Runner requires its own domain name in Host headers
- App Runner's routing functionality identifies requests based on Host Headers
- CloudFront domain Host headers prevent App Runner from processing correctly
AllViewerExceptHostHeader policy is the solution to this problem
- Forwards all request information except Host Header
- CloudFront automatically rewrites Host Header to origin domain

Helpful information sources:

AWS CloudFront managed policies
Next.js image optimization with CloudFront best practices
App Runner Host header requirements

This discovery was the turning point! 🎉

Final Solution Implementation

1. Adding Data Source

# Adding AllViewerExceptHostHeader policy data source
data "aws_cloudfront_origin_request_policy" "all_except_host" {
  name = "Managed-AllViewerExceptHostHeader"
}

2. Unifying All Cache Behaviors

# Default cache behavior
default_cache_behavior {
  cache_policy_id            = "658327ea-f89d-4fab-a63d-7e88639e58f6" # CachingOptimized
  origin_request_policy_id   = data.aws_cloudfront_origin_request_policy.all_except_host.id
  # Other settings...
}

# Image optimization specific behavior
ordered_cache_behavior {
  path_pattern               = "_next/image*"
  cache_policy_id            = "4135ea2d-6df8-44a3-9df3-4b5a84be39ad" # CachingDisabled
  origin_request_policy_id   = data.aws_cloudfront_origin_request_policy.all_except_host.id
  # Other settings...
}

# Static assets behavior
ordered_cache_behavior {
  path_pattern               = "_next/static/*"
  cache_policy_id            = "658327ea-f89d-4fab-a63d-7e88639e58f6" # CachingOptimized
  origin_request_policy_id   = data.aws_cloudfront_origin_request_policy.all_except_host.id
  # Other settings...
}

AWS Managed Policies Used - Detailed Overview 📊

Here's a summary table of the managed policies used for this solution:

Policy Name	Policy ID	Purpose	Key Points
AllViewerExceptHostHeader	`b689b0a8-53d0-40ab-baf2-68738e2966ac`	Auto Host Header rewriting	🔑 Most critical policy
CachingDisabled	`4135ea2d-6df8-44a3-9df3-4b5a84be39ad`	Image optimization (dynamic processing)	For real-time processing
CachingOptimized	`658327ea-f89d-4fab-a63d-7e88639e58f6`	Static asset caching	Performance improvement

Why AllViewerExceptHostHeader Policy is Critical

The excellent features of this policy include:

Automatic Host Header Rewriting
- CloudFront automatically changes Host Header to App Runner domain
- Enables App Runner to route correctly
- Example: Host: xxxxxx.cloudfront.net → Host: xxxxx.ap-northeast-1.awsapprunner.com
Complete Request Information Forwarding
- Reliably forwards all query parameters (url, w, q, etc.)
- Properly forwards important header information like Accept, User-Agent, Authorization
- Preserves cookies and referrer information
Configuration Simplicity
- No need for complex forwarded_values settings
- No need to specify individual headers or query parameters
- AWS-managed, ensuring future compatibility
Performance Optimization
- Reduces overhead by avoiding unnecessary Host Header forwarding
- Speeds up App Runner routing processing
- Improves CDN cache efficiency

Comparison with legacy forwarded_values settings:

# ❌ Legacy complex configuration
forwarded_values {
  query_string = true
  headers = [
    "Authorization",
    "Accept",
    "Accept-Language",
    "Accept-Encoding",
    "Origin",
    "Referer",
    "User-Agent"
    # Host needs to be excluded but individual specification is cumbersome
  ]
  cookies {
    forward = "all"
  }
}

# ✅ Using AllViewerExceptHostHeader policy
origin_request_policy_id = data.aws_cloudfront_origin_request_policy.all_except_host.id
# Done in just one line above!

Verification Results and Effects ✅

Before Fix

❌ Site accessible via CloudFront but images not displayed
❌ 400 Bad Request at /_next/image endpoint
❌ Host Header mismatch and query parameter forwarding issues

After Fix

✅ Site completely displays including images via CloudFront
✅ Next.js image optimization functions normally
✅ Speed improvement due to static asset cache effects
✅ Improved configuration reliability through managed policies

When I confirmed the site after the fix, I was truly happy! 🎉

Summary 🎯

Through solving this CloudFront + Next.js image optimization error, the following key points became clear:

✅ Key Solution Points

Introduction of AllViewerExceptHostHeader policy - Fundamental solution to Host Header issues
Proper cache policy differentiation - Balancing performance and functionality
Systematic debugging approach - Essential understanding of problem nature

✅ Technical Achievements

Complete functionality of Next.js image optimization via CloudFront
Simplified and reliable configuration through managed policy utilization
Performance improvements (static asset cache effects)

✅ Future Applications

Applicable as knowledge for other Next.js + CDN configurations
Best practices when using App Runner
Reference for effective AWS managed policy utilization

While CloudFront and Next.js combinations can become complex in configuration, this demonstrates that proper approaches can definitely solve such issues. I hope this helps others facing similar problems!

If you know better methods or have additional improvement suggestions, please let me know! 🙇‍♂️

Test Environment: AWS App Runner + CloudFront + Next.js
Resolution Date: 2025-06-21
Result: ✅ Complete functionality of image optimization via CloudFront
